Materials We Offer for Custom CNC Machining and Manufacturing
Top Proto stocks and processes over 50 engineering metals, plastics, and composite materials across our CNC machining, injection molding, sheet metal fabrication, and 3D printing operations. Every material is sourced from certified suppliers with mill certifications confirming alloy composition and mechanical properties. Material selection for your part should be based on the application’s load requirements, operating temperature range, chemical exposure, surface finish requirements, and weight constraints — and our engineering team is available to review your specification and recommend the most appropriate material before production begins.
- All uploads are secure and confidential
Metal Materials for CNC Machining
Our CNC machining capabilities extend across a vast range of metallic alloys, ensuring structural integrity and thermal resistance for every component.
Material | Grade / Spec | Key Properties | Common Applications |
|---|---|---|---|
Aluminum | 6061-T6 | Excellent machinability, good strength-to-weight, anodizable | Structural brackets, housings, aerospace panels |
Aluminum | 7075-T6 | Highest strength aluminum, good machinability, anodizable | Aerospace, robotics links, high-load structural parts |
Aluminum | 5052-H32 | Best formability, excellent corrosion resistance | Sheet metal enclosures, marine components |
Aluminum | 6063-T5/T6 | Best anodizing surface quality, architectural alloy | Extrusion profiles, decorative enclosures |
Stainless Steel | 304 | Good corrosion resistance, weldable, machinable | Food, medical, industrial components |
Stainless Steel | 316 / 316L | Superior corrosion resistance with molybdenum | Marine, chemical, pharmaceutical parts |
Stainless Steel | 303 | Best machinability of stainless grades | Precision fasteners, turned components |
Titanium | Grade 5 (Ti6Al4V) | Highest strength-to-weight, biocompatible | Aerospace, medical implants, high-performance parts |
Brass | C360 | Highest machinability rating, good conductivity | Fittings, connectors, valve bodies |
Copper | C101 | Maximum electrical and thermal conductivity | Busbars, heat spreaders, RF components |
Mild Steel | A36 / S235 | Low cost, good weldability and machinability | Structural brackets, chassis, machine parts |
Tool Steel | D2 / H13 / A2 | High hardness, wear resistance | Mold inserts, punches, cutting tools |
Inconel | 718 | Excellent high-temperature strength and corrosion resistance | Aerospace engine parts, exhaust components |
Plastic Materials for CNC Machining
Material | Grade | Key Properties | Common Applications |
|---|---|---|---|
ABS | Standard | Good impact resistance, easy to machine, paintable | Prototype housings, consumer electronics enclosures |
Polycarbonate (PC) | Standard / Optical | High impact strength, optically transparent | Light covers, sight glasses, safety components |
Nylon (PA) | PA6 / PA66 / PA66-GF30 | Good mechanical strength, wear resistance | Gears, bushings, structural brackets |
POM (Delrin) | Homopolymer / Copolymer | Low friction, high stiffness, dimensional stability | Gears, cams, sliding mechanism parts |
PTFE (Teflon) | Virgin PTFE | Chemical resistance, lowest friction coefficient | Seals, bushings, chemical-contact components |
PEEK | Natural / Glass-filled | Exceptional thermal and chemical resistance | Aerospace, medical, semiconductor components |
Ultem (PEI) | 1010 / 9085 | High thermal resistance, flame retardant | Aerospace interiors, sterilizable medical parts |
Acrylic (PMMA) | Cast / Extruded | Optical clarity, UV resistance, weather resistance | Display panels, light diffusers, machine guards |
HDPE | Standard | Chemical resistance, low friction, food-safe | Chemical containers, cutting boards, liners |
Polypropylene (PP) | Standard / Glass-filled | Chemical resistance, living hinge capability | Packaging, medical consumables, housings |
Plastic Materials for Injection Molding
Material | Key Properties | Typical Applications |
|---|---|---|
ABS | Impact resistance, surface finish, easy processing | Consumer electronics, automotive interior, housings |
Polypropylene (PP) | Chemical resistance, lightweight, living hinge | Medical consumables, packaging, caps and closures |
Polyethylene (PE) | Flexibility, chemical resistance, low cost | Containers, piping, flexible components |
Polycarbonate (PC) | Optical clarity, high impact strength, heat resistance | Lenses, light covers, safety equipment |
Nylon PA6 / PA66 | Mechanical strength, wear resistance, heat resistance | Gears, structural brackets, automotive parts |
PEEK | Extreme thermal and chemical resistance | Medical, aerospace, semiconductor components |
POM (Delrin) | Low friction, dimensional stability, stiffness | Precision gears, valve bodies, sliding parts |
TPE / TPU | Flexible, rubber-like, overmoldable | Soft-grip surfaces, seals, flexible housings |
Flame-Retardant Grades | UL94 V-0 and V-2 ratings | Electronics housings, enclosures, cable management |
Materials for 3D Printing
Material | Process | Key Properties | Applications |
|---|---|---|---|
Standard Resin | SLA | High detail, smooth surface, brittle | Visual prototypes, masters for vacuum casting |
Tough Resin | SLA | ABS-like toughness, good detail | Functional prototypes, snap-fit parts |
Clear Resin | SLA | Optical clarity, smooth finish | Transparent covers, fluid flow visualization |
Nylon PA12 | SLS | Good mechanical properties, flexible, no supports | Functional prototypes, ducts, complex geometry |
Nylon PA12-GF | SLS | Glass-filled for higher stiffness | Structural functional parts, brackets |
Nylon PA12 (MJF) | MJF | Uniform mechanical properties, fine detail | Functional prototypes, low-volume production |
PA11 (MJF) | MJF | Flexible, impact resistant, bio-based | Living hinges, snap-fits, flexible parts |
PEEK | FDM/SLS | High temperature, chemical resistance | Aerospace, medical, industrial functional parts |
